4-Way 24V Relay

This module contains 4 relays, which is working at 5V while the Max current is 10A.
$5.99
Availability: In stock
SKU
2070006
  • Buy 5 for $5.39 each and save 10%
  • Buy 10 for $5.09 each and save 15%
  • Buy 50 for $4.79 each and save 20%

This module contains 4 relays, which is working at 5V while the Max current is 10A. There're led indicators on the board to show you the working status of the relays.


Features:

  • •  Operating voltage: 5V (I/O input)
  •   Relay working current: 10A@250VAC, 10A@30VDC
  •   Jumper to sent HIGH or LOW active
  •   LED indicator
  • •  Optocoupler isolation

Pinout:

1. DC+: 5V input

2. DC-: Ground

3. IN1-4: INPUT of Relay 1-4

4. NO1-4: Normal open of relay 1-4

5. COM1-4: COM of relay 1-4

6. NC1-4: Normal connected of relay 1-4


Reference:

  • •  Tech-support: support@longan-labs.cc
